TVLogic LVM-246W 24” 8-bit 1920 x 1080 Full HD Display

TVLogic LVM-246W 24” 8-bit 1920 x 1080 Full HD Display
LVM-246W is a reasonable priced broadcast monitor with new full HD and wide viewing angle IPS LCD. It supports various video interface of SD/HD/3G-SDI, HDMI, DVI, Component Video, S-Video and CVBS. Also provides professional features such as Waveform & Vectorscope, Markers, Timecode, Closed Caption and color calibration.
Excl.BTW
€ 2.999,00
OF
Beschrijving

Details

LVM-246W is a reasonable priced broadcast monitor with new full HD and wide viewing angle IPS LCD. It supports various video interface of SD/HD/3G-SDI, HDMI, DVI, Component Video, S-Video and CVBS. Also provides professional features such as Waveform & Vectorscope, Markers, Timecode, Closed Caption and color calibration.
Video

Extra informatie

Specifications

Extra informatie

Display Spec.

 Size  24"
 Resolution  1920 X 1200 (16 : 10)
 Pixe Pitch  0.270mm
 Color Depth  16.7M
 Viewing Angle  178°(H) / 178°(V)
 Luminance  250cd/m2
 Contrast Ratio  1,000 : 1
 Display Area  518(H) x 324(V) mm

Input

 3 X BNC  Analog Input (Component)
 2 X BNC  3G-SDI A/B Channel Input
 1 X HDMI  HDMI Input
 1 X DVI  DVI Input

Output

 3 X BNC  Analog Output (Component)
 2 X BNC  3G-SDI Output

Audio

 Audio In  Embedded Audio/Analog Stereo (Phone Jack)
 Audio Out  Analog Stereo (Phone Jack), Internal Speaker(Stereo)

FPGA Functions

,  3G-SDI Level A/B,  Audio Level Meter Display,  Blue Only,  Focus Assist,  H/V Delay,  Key Lock,  Luma(Y') Zone Check,  Marker,  Mono,  Range Error,  Time Code Display,  UMD,  User Aspect,  Various Scan Modes,  Waveform/Vector,  Zoom

Closed Caption

 CC-608 ANC,  CC-608 LINE 21,  CC-708

Calibration

 TVLogic Color Calibration Utility

Other Functions

 REMOTE   TVLogic’s specification
 USB   Firmware update by USB cable
 Ethernet
 Conversion   SDI-to-SDI,

Options   Carring Case,  ND Acrylic Filter,  Rack Mount Kit(Single),
